2 way column PA/indoor
- britesynth
- Topic Author
- Offline
- New Member
Less
More
7 years 1 month ago - 7 years 1 month ago #24126
by britesynth
2 way column PA/indoor was created by britesynth
Hello and good day!
your thoughts on this...
[/img] ibb.co/kXCo5w [/img]
advice
1. speaker amp matching (impedance)
2. watts/power and amp matching
3. speaker connection
4. is it worth the build?
I already have the amp so I thought of building a column that will match it
thanks in advance!
-jake
philippines
your thoughts on this...
[/img] ibb.co/kXCo5w [/img]
advice
1. speaker amp matching (impedance)
2. watts/power and amp matching
3. speaker connection
4. is it worth the build?
I already have the amp so I thought of building a column that will match it
thanks in advance!
-jake
philippines
Last edit: 7 years 1 month ago by britesynth.
Please Log in or Create an account to join the conversation.
- britesynth
- Topic Author
- Offline
- New Member
Less
More
- Posts: 4
- Thank you received: 0
7 years 2 days ago #24157
by britesynth
Replied by britesynth on topic 2 way column PA/indoor
up!
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 920
- Thank you received: 132
7 years 2 days ago #24161
by Cubo15
Replied by Cubo15 on topic 2 way column PA/indoor
You question is very general, so yes it could work but there are many pitfalls, that you probably don't know about. So my advice would be to build an existing design, that has done the maths for you.
Please Log in or Create an account to join the conversation.
- britesynth
- Topic Author
- Offline
- New Member
Less
More
- Posts: 4
- Thank you received: 0
6 years 11 months ago #24168
by britesynth
Replied by britesynth on topic 2 way column PA/indoor
hello mr. cubo, I want to know if my speaker connections are right together with wattage and impedance, thank you very much!
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 920
- Thank you received: 132
6 years 11 months ago #24171
by Cubo15
Replied by Cubo15 on topic 2 way column PA/indoor
Your speaker connections (and impedance) are right, however crossovers should take more into consideration then power handling. Sensitivity is just as, if not more important then power handling. Matching sensitivity (expressed as dB/W/meter or dB/ 2.83 V/ meter), combined with the correct crossover frequency, will make sure that the tweeter and four mid drivers are in balance with each other.
Last but not least, a tweeter that boasts that it can handle 100 W without giving much other information, usually can handle nowhere near 100 W.
Best regards
Last but not least, a tweeter that boasts that it can handle 100 W without giving much other information, usually can handle nowhere near 100 W.
Best regards
Please Log in or Create an account to join the conversation.
- britesynth
- Topic Author
- Offline
- New Member
Less
More
- Posts: 4
- Thank you received: 0
6 years 11 months ago #24178
by britesynth
Replied by britesynth on topic 2 way column PA/indoor
thank you mr. cubo!
any suggestion to replace this setup?
btw looking forward to building my own cubo15, just completing the parts
what would be a near perfect match for a cubo15?
10"s 12"s or 15"s? single or double?
planning on having 2 cubo15s per side
sorry for having lots of question
thanks again!
any suggestion to replace this setup?
btw looking forward to building my own cubo15, just completing the parts
what would be a near perfect match for a cubo15?
10"s 12"s or 15"s? single or double?
planning on having 2 cubo15s per side
sorry for having lots of question
thanks again!
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 920
- Thank you received: 132
6 years 11 months ago #24180
by Cubo15
Replied by Cubo15 on topic 2 way column PA/indoor
For a single Cubo 15 per side, I would look into a decent 12"/1" top cabinet. If you have a good 12"/1" top cabinet, you can use 2 Cubo 15's per side. Something like the 18Sound:
www.eighteensound.com/Portals/0/Enclosur...und_12_2_Ways_v1.pdf
or the B&C
www.bcspeakers.com/media/W1siZiIsIjIwMTM...IvNTYvZmlsZSJdXQ.pdf
Of course a decent 2 x 10", or 2 x 12" will also work. I would avoid using top cabinets that use a 15" driver unless you're stepping up to an 1.4" compression driver (which is pricey).
Best regards Cubo
Of course a decent 2 x 10", or 2 x 12" will also work. I would avoid using top cabinets that use a 15" driver unless you're stepping up to an 1.4" compression driver (which is pricey).
Best regards Cubo
